TM200CE24R-ControllerM20024IOrelay+Ethernet
في الأوراق المالية

TM200CE24R Controller M200 24 IO relay+Ethernet

رمز التخزين التعريفي : SATM200CE24R
يصنع : GENERIC
نموذج : TM200CE24R
التوفر : في الأوراق المالية
Generic
AED 0.00 - AED 0.00
AED 0.00
AED 3,100.00
AED 3,100.00 - AED 3,100.00
AED 3,100.00
(بما في ذلك ضريبة القيمة المضافة)

TM200CE24R Controller M200 24 IO relay+Ethernet

This product is part of the Easy modicon M200 range, an offer of logic controllers for up to 168 I/O, 2 axis motion control. This logic controller provides 4 fast inputs, 4 high speed inputs, 6 regular inputs and 10 relay outputs, normally opened relay output.

It is a Modicon logic controller with an input voltage of 24V DC, a discrete output voltage of 24V DC, 220V AC and an output current of 2A. Easy to maintain and update with its micro SD memory card. Integrated connections are mini B USB 2.0, serial link 1 and RS 485, serial link 2 and RS 232/RS 485, ethernet Modbus TCP/IP, and serial link 2 and RS 485.

It is a controller with an internal flash of 512byte and a micro SD card capacity of 32GB. It is an IP20 rated product. Its dimensions are 130mm (Width) x 70mm (Depth) x 90mm (Height). It weighs 0.413kg. Designed for textile, machine tool, packaging, material handling, pumping, hoisting, electronic assembly machines.

TM200CE24R Controller M200 24
Product Easy Modicon M200
Component Type Logic controller
Rated supply voltage 100…240 V AC
Discrete I/O number 24
Discrete input number I2…I5: 4 fast input
I0, I1, I6, I7: 4 high speed input
I8…I13: 6 regular input
Discrete output number 10 relay
Discrete input voltage 24 V
Download Data Sheet : Download
Download Catalog: Download
