Atmospheric Pressure Transmitter CP 116
In stock

Atmospheric Pressure Transmitter CP 116

SKU : SRCP116
MAKE : SAUERMANN
MODEL : CP 116
WARRANTY : 1 Year
AVAILABILITY : IN STOCK
Sauermann
AED 1,000.00 - AED 1,000.00
AED 1,000.00
AED 1,400.00
AED 1,400.00 - AED 1,400.00
AED 1,400.00
(Including VAT)

Atmospheric Pressure Transmitter CP 116

The CP 116 Atmospheric Pressure Transmitter is a precise and reliable instrument designed to measure atmospheric pressure in a wide range of industrial and environmental applications. Engineered for accuracy, the CP 116 provides real-time pressure readings in mbar, mmHG, or hPa, ensuring consistent monitoring of environmental conditions. Its robust ABS housing with IP65 protection makes it suitable for use in challenging environments. Available with or without a digital display, this transmitter is easy to install and integrate into existing systems, making it an ideal choice for both new and retrofit projects.

Features

  • High Accuracy: Delivers precise pressure measurements with an accuracy of ±3 hPa, ensuring reliable data for critical applications.
  • Wide Measurement Range: Measures atmospheric pressure from 800 to 1100 hPa, covering a broad spectrum of environmental conditions.
  • Flexible Output Options: Offers 0-10 V or 4-20 mA active outputs, or a 4-20 mA passive loop output, accommodating various system requirements.
  • Durable Construction: Housed in an ABS V0 enclosure, rated IP65, providing protection against dust and water ingress.
  • Optional Display: Available with a 10-digit LCD display for clear and immediate pressure readings.
  • Easy Installation: Features a "¼ turn" mounting system with a wall-mount plate for quick and secure installation.
  • Fast Response Time: Provides a response time of less than 10 seconds, ensuring timely data collection.
Measuring Range

 800 to 1100 hPa



Accuracy

 ±3 hPa



Output





Active

 0-10 V or 4-20 mA (24 Vac/Vdc ±10%)



Passive

 4-20 mA loop-powered (16-30 Vdc)



Housing Material

 ABS V0 as per UL94



Protection Class

 IP65



Display

 Optional LCD, 10 digits, size 50 x 17 mm



Resolution

 1 mbar; 1 hPa; 1 mmHG



Overpressure Tolerance

 Up to 4136 hPa



Operating Temperature

 0 to +50°C



Storage Temperature

 -10 to +70°C



Power Consumption

 2 VA (0-10 V) or 0.6 VA (4-20 mA)



Dimensions

 170 x 105 x 54 mm



Weight

 143 g



  • Included:
    • Wall-mount plate
    • Cable gland
    • Instruction manual
  • Optional:
    • LCC-S Configuration software with USB cable
    • Power supply units (KIAL-100A for 24 Vac, KIAL-100C for 24 Vdc)
    • Connection tube and fittings
    • Calibration certificate
Datasheet : Download

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Q1: What is the primary use of the CP 116 Atmospheric Pressure Transmitter?

A1: The CP 116 is primarily used for monitoring atmospheric pressure in industrial and environmental applications, ensuring accurate data for system regulation and environmental analysis.

Q2: Can the CP 116 be configured for specific outputs?

A2: Yes, the CP 116 can be configured to provide 0-10 V or 4-20 mA active outputs, as well as a 4-20 mA passive loop output, depending on your system requirements.

Q3: What is the protection rating of the CP 116?

A3: The CP 116 is rated IP65, offering robust protection against dust and water ingress, making it suitable for challenging environments.

Q4: Does the CP 116 come with a display?

A4: The CP 116 is available with or without a digital LCD display, depending on your needs.

Q5: What is the response time of the CP 116?

A5: The CP 116 has a response time of less than 10 seconds, ensuring timely and accurate pressure readings.

Q6: How is the CP 116 mounted?

A6: The CP 116 features a "¼ turn" wall-mount system with an ABS plate for quick and secure installation.

Atmospheric Pressure Transmitter CP 116

The CP 116 Atmospheric Pressure Transmitter is a precise and reliable instrument designed to measure atmospheric pressure in a wide range of industrial and environmental applications. Engineered for accuracy, the CP 116 provides real-time pressure readings in mbar, mmHG, or hPa, ensuring consistent monitoring of environmental conditions. Its robust ABS housing with IP65 protection makes it suitable for use in challenging environments. Available with or without a digital display, this transmitter is easy to install and integrate into existing systems, making it an ideal choice for both new and retrofit projects.

Features

  • High Accuracy: Delivers precise pressure measurements with an accuracy of ±3 hPa, ensuring reliable data for critical applications.
  • Wide Measurement Range: Measures atmospheric pressure from 800 to 1100 hPa, covering a broad spectrum of environmental conditions.
  • Flexible Output Options: Offers 0-10 V or 4-20 mA active outputs, or a 4-20 mA passive loop output, accommodating various system requirements.
  • Durable Construction: Housed in an ABS V0 enclosure, rated IP65, providing protection against dust and water ingress.
  • Optional Display: Available with a 10-digit LCD display for clear and immediate pressure readings.
  • Easy Installation: Features a "¼ turn" mounting system with a wall-mount plate for quick and secure installation.
  • Fast Response Time: Provides a response time of less than 10 seconds, ensuring timely data collection.
Measuring Range

 800 to 1100 hPa



Accuracy

 ±3 hPa



Output





Active

 0-10 V or 4-20 mA (24 Vac/Vdc ±10%)



Passive

 4-20 mA loop-powered (16-30 Vdc)



Housing Material

 ABS V0 as per UL94



Protection Class

 IP65



Display

 Optional LCD, 10 digits, size 50 x 17 mm



Resolution

 1 mbar; 1 hPa; 1 mmHG



Overpressure Tolerance

 Up to 4136 hPa



Operating Temperature

 0 to +50°C



Storage Temperature

 -10 to +70°C



Power Consumption

 2 VA (0-10 V) or 0.6 VA (4-20 mA)



Dimensions

 170 x 105 x 54 mm



Weight

 143 g



  • Included:
    • Wall-mount plate
    • Cable gland
    • Instruction manual
  • Optional:
    • LCC-S Configuration software with USB cable
    • Power supply units (KIAL-100A for 24 Vac, KIAL-100C for 24 Vdc)
    • Connection tube and fittings
    • Calibration certificate
Datasheet : Download

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Q1: What is the primary use of the CP 116 Atmospheric Pressure Transmitter?

A1: The CP 116 is primarily used for monitoring atmospheric pressure in industrial and environmental applications, ensuring accurate data for system regulation and environmental analysis.

Q2: Can the CP 116 be configured for specific outputs?

A2: Yes, the CP 116 can be configured to provide 0-10 V or 4-20 mA active outputs, as well as a 4-20 mA passive loop output, depending on your system requirements.

Q3: What is the protection rating of the CP 116?

A3: The CP 116 is rated IP65, offering robust protection against dust and water ingress, making it suitable for challenging environments.

Q4: Does the CP 116 come with a display?

A4: The CP 116 is available with or without a digital LCD display, depending on your needs.

Q5: What is the response time of the CP 116?

A5: The CP 116 has a response time of less than 10 seconds, ensuring timely and accurate pressure readings.

Q6: How is the CP 116 mounted?

A6: The CP 116 features a "¼ turn" wall-mount system with an ABS plate for quick and secure installation.
