In stock

Magnetic Flaw Detector Magnetic Yoke NOVOTEST MPD-DC

Name: Magnetic Flaw Detector Magnetic Yoke NOVOTEST MPD-DC
Brand: Novotest
SKU: NMYMPDDC
Price: 1800.0 AED
Availability: InStock

SKU : NMYMPDDC

MAKE : NOVOTEST

MODEL : MPD-DC

AVAILABILITY : IN STOCK

AED 0.00 - AED 0.00

AED 0.00

AED 1,800.00

AED 1,800.00 - AED 1,800.00

AED 1,800.00

(Including VAT)

Description

Specification

Data sheets

Reviews

Magnetic Flaw Detector Magnetic Yoke NOVOTEST MPD-DC

Magnetic Flaw Detector (Magnetic Yoke) NOVOTEST MPD-DC applies in circumstances where the electric equipment mustn’t be used or prohibited by the rules.Device is used during magnetic particle inspection (where it is applicable) according to ASTM E 709, ASTM E 1444, ASME Section V Article 7 and MIL-STD-1949.Magnetic Flaw Detector NOVOTEST MPD-DC is used to detect surface and subsurface cracks of all kinds (flake, lack of fusion welded joints, tears etc.) in structures made of ferromagnetic materials.The device has two permanent magnets placed in a cylindrical shells, which are connected by a flexible magnetic wire, so it can be used for MPI of remote locations, corner welds and other products of various shapes and sizes.

Magnetic field strength at the center of the air gap between the poles	200 kA / m
Magnetic field strength in the air in the middle region between the working ends of the magnet, not less	65 kA / m
Lift force, not less	22 kg (50 pounds)
Interpolar distance	350 mm
Weight of the device, not more	0.6 kg
Dimensions – cylindrical – flexible magnetic core	40120360 mm

Description

Magnetic Flaw Detector Magnetic Yoke NOVOTEST MPD-DC

Specification

Magnetic field strength at the center of the air gap between the poles	200 kA / m
Magnetic field strength in the air in the middle region between the working ends of the magnet, not less	65 kA / m
Lift force, not less	22 kg (50 pounds)
Interpolar distance	350 mm
Weight of the device, not more	0.6 kg
Dimensions – cylindrical – flexible magnetic core	40120360 mm
